SBM091

2

BORE X STROKE MM. :

114.3 x 116L

3

DISPLACEMENT VOLUME CC :

1191

4

RATED OUTPUT :kw/RPM
    AS PER IS:11170-1985:hp/RPM

6.75/1000
9/1000

5

SPECIFIC FUEL :g/kwh
  CONSUMPTION (SFC):g/hph

250 g/kwh
184 g/hph

6

TORQUE AT CRANKSHAFT DRIVE
kNm
Kgm
RPM

0.056
(5.73)
1500

7

COMPRESSION RATIO :

17:01

8

STARTING SYSTEM :

BY HAND CRANKING AT CAMSHAFT EXTENSION / ELECTRIC START OPTIONAL

9

FUEL :

HIGH SPEED DIESEL [HSD]

10

LUBRICATING OIL :

SAE-30 / SAE-40 OR ANY EQUIVALENT GRADE

11

LUBRICATING OIL :
      SUMP CAPACITY (Ltr)

3 lts.

12

LUBE OIL CONSUMPTION :

APPX 1 to 1.5% OF SFC

13

FOUNDATION BOLT SIZE MM. :

292 X 140

14

CRANKSHAFT CENTRE HEIGHT MM.:

From Bottom 200 mm - From Foundation 90 mm

15

GOVERNING

CLASS B1 AS PER IS : 10000 (PART 7) 1980

17

NET WT. KGS :

300 Kgs

18

GROSS WT. KGS :

370 Kgs

19

WOODEN CASE SIZE MM. :

102 x 78 x105
